Home > Products > sand cast iron > Round Glass Spigot Without Base

Round Glass Spigot Without Base

  • Round Glass Spigot Without Base
  • Round Glass Spigot Without Base
  • Round Glass Spigot Without Base
  • Round Glass Spigot Without Base

Round Glass Spigot Without Base

    Unit Price: 16~20 USD
    Min. Order: 20 Piece/Pieces
    Packaging: one piece glass spigot with bubble bad then into one little carton ,eight pieces into one outer carton
    Productivity: 10000
    Brand: shengyu
    Transportation: Ocean,Air
    Place of Origin: shandong
    Supply Ability: 10000
    Certificate: ISO9001
    Port: qingdao,yantai,tianjin

Basic Info

Model No.: SY001-08

Product Description

Cast Iron pipes must be resistant to corrosion and high pressure. Other castings must be lightweight but durable. In many applications, parts are designed to allow precise tolerances between expansion and contraction.

serial number. SY001-08
product name stainless steel faucet
brand Sheng Yu
high 160mm, also have 180mm, 220mm, can be customized
Material Stainless Steel 304/316, Duplex 2205
surface satin, mirror, gold-plated, powder-coated
weight 1.3kg
size 150*50*50mm
colour Stainless steel color, white, black, gold, champagne, red, green, etc.
shape Round/Rectangular/Oval Deck Mount or Side Mount Faucet, Customizable
Applicable glass thickness 8mm, 10mm, 12mm, also 15mm or 5/16", 3/8", 1/2", 9/16" tempered glass panels...etc.
Advantage -Through integral casting, our faucets have the advantage of high strength and safety -glass panels do not require holes -easy to install-focus on DIY -perfect for glass swimming pools, glass gardens, railings, stairs, etc.

BY

Invest in the foundry process


In investment casting, wax or a suitable polymer pattern is applied by dipping into a refractory slurry. Once the refractory coating has hardened, the dipping process is then repeated several times to increase coating thickness and strength. Once the final coating hardens, the wax melts and the molten metal is poured into the cavity formed by the wax mold. Once the metal has solidified within the mold, the metal casting is removed by breaking the refractory mold.

Investment Casting produces precision parts while minimizing material waste, energy and subsequent processing. It also ensures the production of very complex parts. This makes the investment casting process very useful for design engineers.

A. Mold Design

It uses a pattern with the same detail as the finished part, except that there is an allowance for thermal shrinkage (i.e. shrinkage).

Patterns are usually made from wax using metal injection molds.

B. Waxing

#glassspigot #poolfencing #glassfencing #glassfittings #glasshardware #glassclip #glasspoolfencing #framelessglass #glassbalustrade #glassclamp #glasspost #semiframelessglass #framelessglassfencing #privacyfencing #glassstands #framelessfencing #glassrailing #usglassfencing #caglassfencing

Once the wax pattern is produced, it is assembled with other wax components to form the gate and runner metal delivery system.

Depending on the size and configuration of the desired veneer components, multiple wax patterns can be processed with a single tree.

C. Create the mold shell

The entire wax mold assembly is dipped in a ceramic slurry, covered with sand plaster, and allowed to dry.

The soaking and subsequent stucco cycles are repeated until a shell of the desired thickness is formed. This thickness depends in part on product size and configuration.

Once the ceramic shell dries, it becomes strong enough to retain molten metal during casting.

D. Wax removal

The entire assembly was placed in a steam autoclave to melt most of the wax.

Any wax that remains in the ceramic casing will burn off in the furnace. At this point, the residual wax mold and casting material have been completely removed, and the ceramic mold still has a cavity in the shape of the desired casting.

This high temperature operation also increases the strength and stability of the ceramic material. Additionally, it helps minimize shell and metal reactions during the pouring process.

E. Casting

A metal casting is formed by preheating a mold to a specific temperature and filling it with molten metal.

Almost any alloy can be produced using this process. Depending on the requirements of the alloy chemistry, air melting or vacuum melting can be used. Vacuum melting is mainly used when active elements are present in the alloy.

F. Final Actions

Once the casting has cooled sufficiently, the mold shell is detached from the casting in a demolding operation.

Gates and runners are cut from the casting and, if necessary, final post-processing blasting, grinding, and machining to complete the casting to size.

NDT may include fluorescent penetrants, magnetic particles, radiography.

Frameless glass railing socket


DONGYING SHENGYU METAL PRODUCT CO.,LTD

  • 1
  • 2
  • 3
  • 4
  • 5


Welcome to Dongying ShengYu Metal Product Co., LTD,We are located in Dong Ying city ShangDong China , we are specialized casting manufacturer including tooling ,investment casting,precision machining,surface treatment and assembly.

Currently, our Investment Casting foundry covers an area of 40,000 square meters. There are total 200 workers in our factory, with 159 workers, 5 engineers, 18 QC man, 6 sales person, and 12 management., our company is a large-scale professional investment casting foundry with powerful machining capabilities in China. It consists of 2 major facilities, both steel casting foundry and CNC machining factory which enable us to supply Precision Casting parts with annual capacity of over 5,000 tons, and the products are mainly exported to Canada ,United States, Australia, Germany, UK, Japan etc.

ShengYu has passed the government's completely environmental assessment, which can ensure the long-term and sustainable production.

ShengYu has excellent technology research and development team relies on strong R&D ability, the company is good at producing various complex and difficult Precision castings products and take the machined of various materials such as stainless steel, heat resistant Steel, carbon steel ,low-alloy steels,high temperature alloy, non-ferrous alloys.We are committed to producing Quality Investment Castings at the lowest possible price and on time delivery. Up to today, more than 100 raw materials and 5,000 kinds of different products have been developed and produced by us.

Our products mainly involve following areas ,fluid equipment parts,Pumps & Valves,Impeller parts,,Building Hardware, Marine Hardware, Automobile and Fabrication customized parts. Our advantages manufacture over 15 years experience in casting, design and development customized Auto CAD ,UG Pro and E Solid Works for 2D and 3D drawings.

The company is already passed all kinds of certifications like ISO 9001.IRIS. At the same time, we have complete testing equipment, such as: Coordinate Measuring Machine,Optical Emission Spectrometer,Dynamic balance teste,Salt Spray Tester etc. Strong detection ability and rich casting experience have always getting good reputation from customers all over the world.

The company has set its strategic objective which is [Leading development in this industry, striving to provide a casting enterprise with core competitiveness and core value", confirmed with its core competitiveness that [Leading Ideas, Advanced Equirpments, Excellent QC, and Perfect Services". It sticks to the quality management philosophy that [Starting from the customer needs and ending with their satisfaction, focusing on customer demands and exceeding their expectations"


Company Info

  • Company Name: DONGYING SHENGYU METAL PRODUCT CO.,LTD
  • Representative: Li LongLong
  • Product/Service: Metal Casting , Precision Casting , Building Hardware , Steel Casting , Impeller Parts , Machinery Parts
  • Capital (Million US $): 500RMB
  • Year Established: 2012
  • Total Annual Sales Volume (Million US $): US$50 Million - US$100 Million
  • Export Percentage: 51% - 60%
  • Total Annual Purchase Volume (Million US $): US$5 Million - US$10 Million
  • No. of Production Lines: 2
  • No. of R&D Staff: 11 -20 People
  • No. of QC Staff: 21 -30 People
  • OEM Services Provided: yes
  • Factory Size (Sq.meters): 10,000-30,000 square meters
  • Factory Location: Longju ecnomic zoon Dongying City Shandong Province
